Dell SCV2020 5H3XX: Deep Dive into Performance & Use Cases

When you see Dell SCV2020 5H3XX, what you’re usually referring to is a storage system (SCv2020) and a hard drive component (part number 5H3XX) used in Dell Compellent / SC storage arrays. In this article, we’ll unpack what the SCv2020 is, what 5H3XX drive means, how they work together, and what to look out for when selecting or maintaining such systems. By the end, you should have a solid understanding of this combo’s relevance in modern data storage setups.

Dell SCV2020 5H3XX — What Does the Name Mean?

To make sense of the term, break it into two parts:

• SCv2020: This is a Dell Compellent / Dell Storage “SC” series system, specifically the SCv2020 model.

• 5H3XX: This is a Dell part (hard drive) number, often tied to enterprise SAS disk drives used inside SCv series systems.

Together, they imply the use of the 5H3XX drive inside a Dell SCv2020 storage chassis or system.

Dell SCV2020 5H3XX: Overview of the Storage System

Dell SCV2020 5H3XX System Architecture & Specs

The Dell SCv2020 is part of the SCv2000 / SCv2020 storage family which offers compact, scalable storage arrays.

Key architectural highlights:

• Supports up to 24 hot-swappable 2.5-inch SAS drives

• Uses redundant, hot-swappable storage controllers (up to 2 controllers)

• Offers front-end connectivity options: Fibre Channel, iSCSI, or SAS depending on configuration

• Back-end SAS expansion capabilities to link additional enclosures (SC100 or SC120)

• Power and cooling are handled in modules: dual power supply / cooling fan modules

Because of its compact form and flexibility, SCv2020 is suited for mid-range storage environments, often in enterprises that need high performance but in a smaller physical footprint.

Use Cases & Deployment Scenarios

Some common use cases for SCv2020 include:

• Virtual machine storage (VMware, Hyper-V)

• Database workloads (small to medium)

• General file / block storage for business apps

• Backup / archival tiers (especially when mixed drive types are used)

• Hybrid setups combining SSD + spinning disk

Its modular nature means you can start with a smaller set of drives and expand later.

5H3XX Drive: Specs & Role

What is 5H3XX?

Part number 5H3XX corresponds to a Dell Compellent / SC-series enterprise SAS drive, typically:

• 1.8 TB capacity

• 10,000 RPM rotational speed

• 12 Gb/s SAS interface (SAS-3)

• 2.5-inch / small form factor (SFF) size

• Enterprise class (often labeled “Enterprise Plus”) controller’s management.

Compatibility & Target Arrays

The 5H3XX drive is commonly used in Dell Compellent / SC series arrays, including:

• SCv2020

• SCv3020 / SCv420 / SCv5020 / SCv7020 (in some configurations)

Always verify firmware compatibility and array support lists, as enterprise storage arrays often require certified drive firmware to ensure reliability and performance.

How SCv2020 & 5H3XX Work Together

Storage Layout & RAID Strategy

In an SCv2020 chassis using 5H3XX drives, data is laid out by the system’s Storage Center OS (Dell’s software layer). Some important points:

• The system may use thin provisioning, automated tiering, and data movement between drive tiers.

• You can mix drives (e.g. faster SAS or SSD) in certain tiers depending on your performance needs.

• RAID settings are managed at the controller level, and the system ensures redundancy.

Because 5H3XX is a high performance drive (10K, SAS-3), it is often part of the performance tier in hybrid arrays.

Performance & Throughput

Given 12 Gb/s SAS interface and 10,000 RPM speed, a 5H3XX drive is capable of solid performance in random I/O and sequential workloads (within mechanical limits). However:

• The effective throughput will depend heavily on queue depth, workload type (random vs sequential), and controller / caching strategy.

• For workloads demanding very high IOPS, multiple drives in parallel are essential.

• The controller, cache, and interconnect (front-end ports) must not choke the system.

In a balanced system, the SCv2020 with 5H3XX drives offers a capable mid-tier performance envelope.

Advantages & Limitations of SCv2020 5H3XX Setup

Advantages

• Enterprise-grade reliability: Both SCv2020 and 5H3XX are built for enterprise use.

• Scalability: You can expand via enclosures (SC100 / SC120) and more drives.

• Flexibility in connectivity: Supports multiple protocols (Fibre Channel, iSCSI, SAS).

• Moderate footprint: 2.5-inch format and compact design help when rack space is limited.

• High throughput drive: 10K SAS drives are faster than typical 7.2K ones, good for mixed workloads.

Limitations & Considerations

• Mechanical drive constraints: Being a spinning disk, latency and seek time will be nontrivial for random workloads.

• Power & cooling demand: High RPM drives plus multiple modules require good cooling and clean power.

• Firmware & compatibility: Using non-certified drives can cause instability.

• Cost vs SSD: In many cases, SSDs or NVMe will outperform, although at higher cost.

• Expansion complexity: If you scale far, managing tiers, migrations, and interconnects may require careful design.

Best Practices for Deploying Dell SCV2020 5H3XX with 5H3XX

Drive Selection & Firmware

• Use Dell-certified drives with supported firmware for that SC series.

• Before inserting new drives, ensure firmware revision matches or is compatible with existing drives.

• Maintain a consistent drive type in a performance tier to avoid unpredictable behavior.

Cooling & Power Design

• Mount in a rack with proper airflow front-to-back.

• Provide redundant power circuits if possible.

• Monitor temperature and ensure fans are functioning within spec.

RAID / Tiering Strategy

• Leverage hybrid tiers: let faster drives or SSDs act as a cache or hot tier; use 5H3XX drives for general pool.

• Use redundancy (e.g. RAID 6 or RAID 10 depending on tradeoffs) so one drive failure doesn’t degrade service critically.

• Plan capacity headroom — always leave some spare drives or blank slots for growth.

Monitoring, Alerts & Maintenance

• Use Dell Storage Manager / SupportAssist to monitor drive health, temperature, and alerts.

• Replace drives preemptively if SMART / system flags warn of failure.

• Schedule maintenance windows for firmware updates (controllers, drives, backplane) with minimal disruption.

Testing & Validation

• Before full deployment, use synthetic workloads to validate IOPS / throughput and confirm no bottlenecks (controller, interface).

• Validate data integrity after drive replacements or array reconfigurations.

• Test failover scenarios (remove one controller, one drive) to ensure redundancy works correctly.

Alternative Options & When to Choose Other Solutions

While an SCv2020 + 5H3XX setup can be strong, you should consider alternatives depending on your needs:

• All-SSD / NVMe arrays: For ultra-low latency or high IOPS, SSDs or NVMe are better.

• Larger arrays / scale-out systems: If your storage needs grow significantly, you may need SAN / scale-out storage systems.

• Use of newer Dell SC / PowerStore / Unity lines: Dell often refreshes its storage product lines; newer systems may offer better efficiency or features.

• Cloud storage / hybrid cloud architectures: For elastic scaling, offload infrequently used data to cloud or integrate cloud tiers.

The SCv2020 + 5H3XX configuration fits a middle ground: high reliability, good performance, at controlled cost.

Example Deployment Scenario & Thought Process

Imagine a mid-size company running a virtualization infrastructure:

1. They install an SCv2020 chassis in their data center rack.

2. Populate 16 slots with 5H3XX drives (1.8 TB, 10K SAS) in the performance tier.

3. Add a few SSDs or faster SAS as a hot tier.

4. Use RAID 10 for critical VM volumes, RAID 6 for file shares.

5. Connect front-end via dual Fibre Channel or iSCSI to redundancy in servers.

6. Monitor and replace failing 5H3XX drives automatically without downtime, thanks to hot-swap and redundancy.

This setup provides consistent performance for VMs, file services, applications, with room to expand.

Future Relevance & Lifecycle Considerations

Given the pace of storage tech, how futureproof is SCv2020 + 5H3XX?

• The mechanical drive (5H3XX) will gradually lag behind SSD/NVMe in performance, so its best use will likely shift to capacity or cold data tiers.

• Dell’s newer storage platforms may phase out older SCv series support over many years; plan migrations.

• Firmware updates will eventually cease; keep spares and plan replacement timelines.

• As workloads evolve (AI, real-time analytics), higher IOPS demands may pressure this combination.

Thus, even though SCv2020 + 5H3XX remains viable now, planning for eventual upgrade or migration is prudent.

Conclusion

• Dell SCV2020 5H3XX is a compact, modular enterprise storage system able to host up to 24 SAS drives, with redundant controllers and multiple connectivity options.

• 5H3XX is a Dell-certified enterprise 1.8 TB, 10,000 RPM, 12 Gb/s SAS drive used in SC / Compellent arrays.

• Together, they form a balanced mid-tier enterprise storage solution, offering performance, reliability, and expansion potential.

• Success depends on using compatible firmware, proper cooling, redundancy, and monitoring.

• Over time, mechanical drives may shift to capacity roles, and platform lifecycle should be managed.
